Soundigital SD12000.1 EVO 4.0 Mono Car Amplifier
Soundigital SD12000.1 EVO 4.0 Mono Car Amplifier
High-output car audio, with your choice of impedance
The SounDigital SD12000.1 EVO 4.0 is a mono car amplifier offered in 1-ohm and 2-ohm versions. Choose the version suited to your speaker configuration and plan the electrical system for the power ratings listed below. Its listed dual power connection and adjustable crossovers give installers options for a purpose-built setup.
Listed power output
| Version | At 12.6 V | At 14.4 V |
|---|---|---|
| 1 ohm | 12,000W RMS at 1 ohm; 7,920W at 2 ohms; 5,227W at 4 ohms | 13,380W RMS at 1 ohm; 8,831W at 2 ohms; 5,828W at 4 ohms |
| 2 ohms | 12,000W RMS at 2 ohms; 7,920W at 4 ohms | 13,380W RMS at 2 ohms; 8,831W at 4 ohms |
Other listed details
- Frequency response: 5 Hz–6 kHz
- Low-pass crossover: 50 Hz–6 kHz
- High-pass crossover: 5–80 Hz
- Damping factor: greater than 200
- Amplifier dimensions: 530 × 225 × 71 mm
- Amplifier weight stated in the prior listing: 7 kg
Imagine the first listening session after a carefully tuned install. Professional installation is recommended; verify impedance, wiring and electrical requirements against the manufacturer's documentation before purchase. Shipping weight is listed separately at checkout.
