Banda BD800.4 Digital Amplifier Module Banda 800.4 Channels 800 Watts RMS - 2 Ohms
Sale price
$97.00
Regular price $139.00
Skip to product information
Banda BD800.4 Digital Amplifier Module Banda 800.4 Channels 800 Watts RMS - 2 Ohms
Sale price
$97.00
Regular price $139.00
The BD800.4 offers 800Wrms with a 4-channel configuration of 200Wrms at 2 Ohms each, or 400Wrms at 4 Ohms on each Bridge. This line is widely used for small and medium-sized systems as it accepts various installation configurations, meeting the most diverse needs of the market, playing any type of speaker.
TECHNICAL SPECIFICATIONS
• Maximum Power 14.4v @ 2 Ohms: 4 x 230 WRMS
• Maximum Power 14.4v @ 4 Ohms: 4 x 150 WRMS
• Maximum Power 14.4v Bridge @ 4 Ohms: 2 x 460 WRMS
• Maximum Power 12. 6v @ 2 Ohms: 4 x 200 WRMS
• Maximum Power 12.6v @ 4 Ohms: 4 x 120 WRMS
• Maximum Power 12.6v Bridge @ 4 Ohms: 2 x 400 WRMS
• Efficiency @ 4 Ohms: 82%
• Efficiency @ 2 Ohms: 78%
• Input Voltage: 9 - 16V
• Input Impedance: 47k Ohms
• THD+N: 1.5%
• Input Sensitivity: 250mV - 3.4V •
Signal to Noise Ratio: 85dB •
Frequency Response: 20 to 20kHz (-3dBs)
• HPF (Subsonic): 90Hz to 20kHz @ 12dBs/8° Linkwitz-Riley
• LPF (Crossover): 20Hz to 90Hz @ 12dBs/8° Linkwitz-Riley
• Recommended Fuse: 50 A
• Resting Current : 700mA
• Maximum Current (sine signal): 80 A
• Maximum Current (musical signal): 40 A
• Power Cables (min. recommended): 10mm
• Output Cables (min. recommended): 2 x 1.5mm / 2 x 15 AWG
• Weight (Kg): 0.82
• Height (mm): 116
• Width (mm): 127
• Depth (mm): 53
RECOMMENDATIONS BEFORE PURCHASE
Check the product's compatibility with your equipment to avoid problems when using! Please check this with your installer or contracted professional before purchase.
Check the voltage, power, impedance and other details that could make the installation unfeasible or cause damage to the product or the vehicle or equipment not covered by the warranty.
For products that require installation, this must be done by a qualified professional. We are not responsible for misuse or incorrect installation carried out by the user or another unqualified person.
TECHNICAL SPECIFICATIONS
• Maximum Power 14.4v @ 2 Ohms: 4 x 230 WRMS
• Maximum Power 14.4v @ 4 Ohms: 4 x 150 WRMS
• Maximum Power 14.4v Bridge @ 4 Ohms: 2 x 460 WRMS
• Maximum Power 12. 6v @ 2 Ohms: 4 x 200 WRMS
• Maximum Power 12.6v @ 4 Ohms: 4 x 120 WRMS
• Maximum Power 12.6v Bridge @ 4 Ohms: 2 x 400 WRMS
• Efficiency @ 4 Ohms: 82%
• Efficiency @ 2 Ohms: 78%
• Input Voltage: 9 - 16V
• Input Impedance: 47k Ohms
• THD+N: 1.5%
• Input Sensitivity: 250mV - 3.4V •
Signal to Noise Ratio: 85dB •
Frequency Response: 20 to 20kHz (-3dBs)
• HPF (Subsonic): 90Hz to 20kHz @ 12dBs/8° Linkwitz-Riley
• LPF (Crossover): 20Hz to 90Hz @ 12dBs/8° Linkwitz-Riley
• Recommended Fuse: 50 A
• Resting Current : 700mA
• Maximum Current (sine signal): 80 A
• Maximum Current (musical signal): 40 A
• Power Cables (min. recommended): 10mm
• Output Cables (min. recommended): 2 x 1.5mm / 2 x 15 AWG
• Weight (Kg): 0.82
• Height (mm): 116
• Width (mm): 127
• Depth (mm): 53
RECOMMENDATIONS BEFORE PURCHASE
Check the product's compatibility with your equipment to avoid problems when using! Please check this with your installer or contracted professional before purchase.
Check the voltage, power, impedance and other details that could make the installation unfeasible or cause damage to the product or the vehicle or equipment not covered by the warranty.
For products that require installation, this must be done by a qualified professional. We are not responsible for misuse or incorrect installation carried out by the user or another unqualified person.
