5-way with quality, precision and protection for the system.
Using state-of-the-art technology, the Crossover X5 Bass Evo features features that make it easy to adjust for maximum sound quality and performance.
The X5 Bass Evo Crossover features fixed 24dB / 8th filter and 12dB / 8th variable, 24dB / 8a subsonic filter, adjustable bass booster from 0 to 14dB and volume control on all tracks, providing more precision and protection to the sound system.
The Crossover X5 Bass Evo features:
5-way (LOW, MID LOW, MID HIGH, HIGH and FLAT);
4 input channels, 2 main and 2 sub (L and R);
12 output channels, 2 mono (L + R) and 10 stereo (L and R).
Inputs: 4 with impedance 12KΩ;
Outputs: 12 with impedance 600Ω;
Maximum input and output level: 10Vpp;
Function management: Microcontrolled;
Bass booster adjustable in low path: 0 to 14 dB;
Harmonic distortion: <0.02% at 1kHz;
Power: 9 to 16Vdc;
Consumption in operation: 390mA;
Stand by consumption: <1mA;
Signal to Noise Ratio:> 95dB (20Hz to 20KHz);
Dimensions mm (W x H x D): 245 x 130 x 45;
• 01 Crossover X5 Bass Evo
• Instruction manual
