ELECTRA 8K8 @ 1 OHM AMPLIFIER MODULE
The ELECTRA line was developed especially for those looking for an incomparable bass. It has a frequency response from 5 to 500Hz (-3dBs). Due to this, ELECTRA will only play Subwoofers, Bass. The BASS BOOST @ 45Hz feature is a plus, further boosting your system's bass.
Designed in a 100% aluminum chassis, it works with a power of 8800 WRMS with 1 input channel for connection and 1 Ohm impedance. It has very low harmonic distortion (less than 1%) and Clipping indicator, forced ventilation and short circuit protection.
- Operating class: Class D bridged - Maximum Power 14.4v @ 1 Ohm: 11000 WRMS - Maximum Power 14.4v @ 2 Ohms: 7000 WRMS - Maximum Power 12.6v @ 1 Ohm: 8800 WRMS - Maximum Power 12, 6v @ 2 Ohms: 5100 WRMS - Efficiency @ 2 Ohms: 84% - Efficiency @ 1 Ohm: 79% - Input Voltage: 9 - 15V - Input Impedance: 100K Ohms - Total Harmonic Distortion + Noise: <1% - Sensitivity Input: 180mV to 2.5V - Signal to Noise Ratio: 85dBs - Frequency Response: 18 to 500Hz (-3dBs) - HPF (Subsonic): 20 - 80Hz @ 12dB/octave Linkwitz-Riley - LPF (Crossover): 80 - 500Hz @ 12dB/octave Linkwitz-Riley - Bass Boost @ 45Hz: Variable 0 to +18dBs - Recommended Fuse: 500 A - Resting Current: ~4.0A - Maximum Current (music signal): 880A - Power Cables (recommended min.): 2 x 50mm / 2 x 0 AWG - Output Cables (recommended min. recommended): ): 2 x 10mm / 2 x 6 AWG - Gain control - Signal input in differential mode - Forced ventilation through micro fans - Blue LED indicator of: Power supply and amplifiers on/On - Red LED indicator of: Output distortion ( Clipping) or short-circuit at the output - Yellow LED indicator of: Battery voltage below specified. - Weight (Kg): 8 - Height (mm): 60 - Width (mm): 264 - Depth (mm): 443
Included Items 01- Banda Electra Bass 8K 1 ohm 01- Manual
